Equipment overview
Our testing environment is customized based on the customer’s requirements and unit under test’s specifications.
Owned Test Systems
We flexibly build and configure the test bench according to the customer’s testing requirements and the specifications of the unit under test.
- Various Dynamometers
- Automation Systems
- Measurement Systems
- Test Fixtures and Auxiliary Equipment
Performance Testing Facilities for Hydrogen Engines Contributing to Carbon Neutrality
Hydrogen Gas Supply
- Installation of a hydrogen trailer with a maximum capacity of approximately 3,000 m³
- Supply pressure from the trailer to the test
bench: 19.6 MPa - Supply pressure to the engine: up to 10 MPa
(Pressure is not variable and must be adjusted each time.) - Safety assurance through explosion‑proof test specifications
Feature:
We are one of the few companies capable of conducting hydrogen engine testing.
Automation system
ENORISE MORPHEE
- Real‑time data acquisition
- Execution of programmed operations
- Execution of real‑time models
- Data editing
Combustion analysis system
ENORISE OSIRIS- Real-time combustion analysis
Dynamometers
- Eddy current dynamometer
・22kW～440kW - AC dynamometer
・300kW/8000rpm - DC dynamometer
・300kW/8000rpm
tLEA (gear box dummy)
The customer’s engine is positioned and adjusted to vehicle‑equivalent dimensions(length and height).
Shafts and Dampers
Shaft and damper selection is performed with full consideration of the customer’s technical requirements and torsional dynamics.
Clutch
The clutch system enables simulated engine start and stop operations.
Fuel flow meter
ONO SOKKI FM2500
Fuel consumption rates for gasoline and diesel are measured with high accuracy.
Laminar Flow Meter
SOKKEN LFC-300
The intake air flow rate of the engine is measured with high accuracy.
Emission gas analyzer
- HORIBA MEXA-ONE EGR
- HORIBA MEXA 1500D EGR
- HORIBA MEXA 1500D
- HORIBA MEXA 1600D
- HORIBA MEXA 1260 EGR
- HORIBA MEXA 1230PM
- AVL SPC472 smart sampler
- AVL smoke meter 415S
Sensor terminal box
ENORISE MIO
- Main measurement items）
- Temperature
- Pressure
- AI
- AO
- DI
- DO
Machining Equipment
- 5‑Axis Machining Centers — 2 units
- 6‑Axis Horizontal Boring & Milling Machine
] Operating range: 2000 × 1500 × 1400mm - Crankshaft Balancer
- General‑Purpose Lathe
- Pipe Benders (Φ80–Φ38) — 5 units
- Shearing Machine
Cutting capacity: 13 t × 1200 mm — 2 units - Press Brake — 2 units
- Additional machining tools and fabrication equipment
Other Major Equipment
Engine Disassembly and Assembly RoomWelding Machines: plasma cutter, argon welding machineHardness, Surface Roughness, and Roundness Measurement Instruments Digital Profile ProjectorTool Measuring Instruments & Electron MicroscopeFuel Combustion Test Equipment with Heating SystemAdditional measurement and fabrication equipment
